[Product] >> Riser card FOR 1U  2U  PCI  PCI-eX


Model: PT191, 32Bit PCI Riser card



Designed for ATXBlade or 1U Standard Chassis
Transform vertical PCI Card insertion to horizontal insertion
Supports standard 5V 32-Bit PCI Cards
Dimensions: Measured without PCI edge finger: 100mm L x 27mm W x 19mm H


Model: PT191R(REVERSE), 32Bit PCI Riser card



Designed for ATXBlade or 1U Standard Chassis
Transform vertical PCI Card insertion to horizontal insertion
Supports standard 5V 32-Bit PCI Cards
Dimensions: Measured without PCI edge finger: 100mm L x 27mm W x 19mm H


Model: PT191R15(REVERSE), 32Bit PCI Riser card



Designed for ATXBlade or 1.5U Standard Chassis
Transform vertical PCI Card insertion to horizontal insertion
Supports standard 32-Bit PCI Cards
Dimensions: Measured without PCI edge finger: 100mm L x 37mm W x 19mm H


Model: PT191HR(REVERSE), 32Bit PCI Riser card



Designed for ATXBlade or 2U Standard Chassis
Transform vertical PCI Card insertion to horizontal insertion
Supports standard 32-Bit PCI Cards
Dimensions: Measured without PCI edge finger: 100mm L x 49mm W x 19mm H


Model: PT193, 32Bit PCI Flexiblem riser card

This 32Bit PCI riser card can be used to orient PCI expansion cards such that they lie flat, at a 90 angle, facing away from the mainboard. This can support PCI expansion cards. Features allow one PCI card to be used in low profile cases.


Model: PT193M, M slot to slot 32Bit PCI Flexiblem riser card

This 32Bit PCI riser card can be used to orient PCI expansion cards such that they lie flat, at a any angle, facing away from the mainboard. This can support PCI expansion cards. Features allow one PCI card to be used in low profile cases.


Model: PT312C, 32Bit PCI 1 TO 2 Flexiblem riser card



This 32Bit PCI flexiblem cable 1 TO 2 SLOT Riser Card, Can compatible all mainboards, facing away from the mainboard. This can support PCI-Express expansion cards. Features allow one PCI card to be used in low profile cases.


Model: PT312, 32Bit PCI 1 TO 2 Flexiblem riser card



This 32Bit PCI flexiblem cable 1 TO 2 SLOT Riser Card, This for VIA Embedded Mainboards only. Features allow one PCI card to be used in low profile cases.


Model: PT313, Fou 2U 32Bit PCI 1 TO 2 riser card



This 32Bit PCI 1 TO 2 SLOT Riser Card, at a 90 angle, facing away from the mainboard. This can support all PCI cards. Features allow one PCI card to be used in low profile cases.


Model: PT322, 32Bit 2-2 slots PCI riser card for 2U case

Designed for ATXBlade or 2U Standard Chassis
Transform vertical PCI Card insertion to horizontal insertion
Supports standard 5V 32-Bit PCI Cards
Supports ATXBlade and standard 1U rackmount chassis
Riser card for 2u Cases, plugs into one PCI slot
Provides a total of 2 PCI slots, 1 slots via outrigger cables
Dimensions: 88mm L x 48mm W x 19mm H


Model: PT323, 32Bit 3-3 slots PCI riser card for 2U case

Designed for ATXBlade or 2U Standard Chassis
Transform vertical PCI Card insertion to horizontal insertion
Supports standard 5V 32-Bit PCI Cards
Supports ATXBlade and standard 1U rackmount chassis
Riser card for 2u Cases, plugs into one PCI slot
Provides a total of 3 PCI slots, 2 slots via outrigger cables
Dimensions: 132mm L x 65mm W x 20mm H


Model: PT326, 62Bit  PCI riser card for 1U case

64bit 1U PCIX Riser Card 3.3V


Model: PT318, PCI-E 16X Flexiblem riser card

This PCI-Express riser card can be used to orient PCI-Express expansion cards such that they lie flat, at a 90 angle, facing away from the mainboard. This can be used with the Commell LV-672 and LV-673NS, both of which support PCI-Express expansion cards. Features allow one PCI-Express card to be used in low profile cases.


Model: PT327, PCI-E 8X riser card

This PCI-Express riser card can be used to orient PCI-Express expansion cards such that they lie flat, at a 90 angle, facing away from the mainboard. This can be used with the Commell LV-672 and LV-673NS, both of which support PCI-Express expansion cards. Features allow one PCI-Express card to be used in low profile cases.


Model: PT327R(REVERSE), PCI-E 8X REVERSE riser card

This PCI-Express riser card can be used to orient PCI-Express expansion cards such that they lie flat, at a 90 angle, . Features allow one PCI-Express card to be used in low profile cases.
Designed for ATXBlade or 1U Standard Chassis
Transform vertical PCI-e Card insertion to horizontal insertion
Supports standard PCI all ver 1X\4X\8X  PCI Cards
Dimensions: Measured without PCI-E 8X edge finger:  32mm W


Model: PT192, PCI-E 16X riser card

This PCI-Express riser card can be used to orient PCI-Express expansion cards such that they lie flat, at a 90 angle, facing away from the mainboard. This can be used with the Commell LV-672 and LV-673NS, both of which support PCI-Express expansion cards. Features allow one PCI-Express card to be used in low profile cases.

Features:
PCB Layers: 4
Interface: PCI-Express 16X
Gold-plated fingers excellent EMI characteristics


Model: PT319, PCI-E 16X riser card

This PCI-Express riser card can be used to orient PCI-Express expansion cards such that they lie flat, at a 90 angle, facing away from the mainboard. This can be used with the Commell LV-672 and LV-673NS, both of which support PCI-Express expansion cards. Features allow one PCI-Express card to be used in low profile cases.


Model: PT328H, PCI-E 16X riser card

This PCI-Express riser card can be used to orient PCI-Express expansion cards such that they lie flat, at a 90 angle, facing away from the mainboard. This can be used with the Commell LV-672 and LV-673NS, both of which support PCI-Express expansion cards. Features allow one PCI-Express card to be used in low profile cases.

edge finger:  40mm W


Model: PT328H(REVERSE), PCI-E 16X riser card

This PCI-Express riser card can be used to orient PCI-Express expansion cards such that they lie flat, at a 90 angle, facing away from the mainboard. This can be used with the Commell LV-672 and LV-673NS, both of which support PCI-Express expansion cards. Features allow one PCI-Express card to be used in low profile cases.

edge finger:  50mm W


We welcome interested parties worldwide to make business negotiations and accept for you shape specified dimensions riser card order.
